United Copper Industries is a prominent Copper Tube for Heating Application & Solar Panels Manufacturer in India, and also supplies efficient and reliable solutions in terms of tubing. We make sure that we are strong and precise using a high-tech process of hot-rolling. Our Copper Capillary Tubing of Solar panels is made to be highly thermal, and our Copper Tube of Heating Elements is made out of high-quality manufacturing material that will last long.
Benefits of Copper Tube For Heating Application & Solar Panels
- Strong resistance to seawater corrosion.
- Excellent heat transfer for marine cooling systems.
- Natural protection against marine biofouling.
Table of Content
- Copper Tubes for Heating Application & Solar Panels Specification
- Types of Copper Tubes for Heating Application & Solar Panels
- Size Chart Of Copper Tubes for Heating Application & Solar Panels
- Chemical Copper Tubes for Heating Application & Solar Panels
- Mechanical Compostion of Copper Tube for Heating Application & Solar Panels
- Application of Copper Tubes for Heating Application & Solar Panels
- Copper Tubes for Heating Application & Solar Panels Stock Available
- Packaging of Copper Tubes for Heating Application & Solar Panels
- Cities We Supply Copper Tubes for Heating Application & Solar Panels in India
- Copper Tubes for Heating Application & Solar Panels Exporter
ASME SB280 Copper Seamless Tube Heating Application, BS 2871/EN 1057 Copper Tube For Heating, Copper Pipes and Tube For Heating Elements Stockist, Copper Tube For Heating Application and Solar Panels Supplier In India
United Copper Industries is a largest Copper Tube for Heating Application & Solar Panels Manufacturer and Supplier in India, which are engineered to fulfil the rigid industrial demands. As the temper of Copper Tube for Heating Application and the even hardness are considered, we supply durable Copper C10300 Tubes to Solar Panels with a high level of reliability in terms of heat transfer efficiency. Table X Copper Tube to Solar Panels is also in our list, with the lowest possible price and high quality to support the large-scale project.
Copper Hard Drawn Tube Heating Elements Manufacturer, Copper Soft Tubes For Solar Panels, Copper Tube Heating Application & Solar Panels manufacturer in India
United Copper Industries is a leading Copper Tube for Heating Application & Solar Panels supplier in India, manufacturing precision tubes in sizes ranging from 6 mm to 22 mm and lengths up to 3–6 meters. Our Table Z Copper Tube for Solar Panels ensures high thermal efficiency for applications such as solar water heaters, heat exchangers, boilers, and HVAC systems. These Heating Application Copper Condenser Tube deliver excellent heat transfer performance and long-term durability. We also lead as a Copper Tube for Induction Furnace manufacturer in India.
Specifications of Copper Tube For Heating Application & Solar Panels
| Copper Tube For Heating Application & Solar Panels | Specifications |
| Specification | ASTM B280, JIS H3300, AS/NZS1571.JIS3300-2006 |
| Material | TU2, C1020T, C10200, T2, C1100, TP1, C1201T, C1200, TP2, C1220T, C12200, C14200, C19400, etc |
| Outer Diameter(OD) | 4mm to 150mm |
| Wall Thickness : | 0.2mm~5mm |
| Length | 1m, 2m, 3m, 6m, or as required. |
| Types | Seamless Pipes, Tube / Inner Grooved Pipes / Square Pipes, Tube / Rectangular Pipes, Tube / Finned Pipes, Tube |
Types Of Copper Tube For Heating Application & Solar Panels
Copper Tube For Heating Application & Solar Panels Size Chart
| I.D. & WALL THICKNESS CHART | |||||||||
| Nominal Tube Size inches | O.D. | I.D. | Wall Thickness | ||||||
| Type | |||||||||
| L | K | Solar Grade | M | L | K | Solar | M | ||
| 1/4 | 0.375 | 0.315 | 0.305 | 0.310 | – | 0.030 | 0.035 | 0.028 | |
| 3/8 | 0.500 | 0.430 | 0.402 | 0.420 | 0.450 | 0.035 | 0.049 | 0.030 | |
| 1/2 | 0.625 | 0.545 | 0.527 | 0.540 | 0.569 | 0.040 | 0.049 | 0.035 | |
| 5/8 | 0.750 | 0.666 | 0.652 | 0.660 | – | 0.042 | 0.049 | 0.030 | |
| 3/4 | 0.875 | 0.785 | 0.745 | 0.770 | 0.811 | 0.045 | 0.065 | 0.038 | |
| 1 | 1.125 | 1.025 | 0.995 | 1.010 | 1.055 | 0.050 | 0.065 | 0.040 | |
| 1-1/4 | 1.375 | 1.265 | 1.245 | 1.258 | 1.291 | 0.040 | 0.055 | 0.035 | |
| 1-1/2 | 1.625 | 1.505 | 1.481 | 1.495 | 1.527 | 0.042 | 0.060 | 0.038 | |
| 2 | 2.125 | 1.985 | 1.959 | 1.980 | 2.009 | 0.042 | 0.070 | 0.045 | |
| 2-1/2 | 2.625 | 2.465 | 2.435 | 2.455 | 2.495 | 0.080 | 0.095 | 0.060 | |
| 3 | 3.125 | 2.945 | 2.907 | 2.930 | 2.981 | 0.090 | 0.109 | 0.070 | |
| 3.5 | 3.625 | 3.425 | 3.385 | 3.410 | 3.459 | 0.100 | 0.120 | 0.080 | |
| 4 | 4.125 | 3.897 | 3.857 | 3.880 | 3.935 | 0.114 | 0.134 | 0.090 | |
| 5 | 5.125 | 4.875 | 4.805 | 4.860 | 4.907 | 0.125 | 0.160 | 0.105 | |
| 6 | 6.125 | 5.845 | 5.741 | 5.800 | 5.881 | 0.140 | 0.192 | 0.120 | |
| 8 | 8.125 | 7.725 | 7.583 | 7.680 | 7.785 | 0.200 | 0.271 | 0.165 | |
Copper Tube For Heating Application Solar Panels Chemical Composition
Copper Cu
99%
Phosphorus P
1%
Copper Tube For Heating Application Solar Panels Mechanical Properties
| Standard | Copper Alloy No. | Mechanical Properties | |||
| Tensile strength (Mpa) | Grain Size (mm) | Elongation(%) | Temper | ||
| EN 1057 | – | O250 | – | O30 or 20 | R250 |
| O220 | – | O40 | R220 | ||
| O290 | – | O3 | R290 | ||
| JIS H3300 | C1100 | 245 ~ 325 | – | – | OL |
| O205 | – | O40 | |||
| O265 | – | – | H | ||
| C1220 | O255 | – | – | H | |
| O205 | O0.040 | O40 | OL | ||
| O205 | 0.025 ~ 0.060 | O40 | O | ||
| 245 ~ 325 | – | – | 1/2H | ||
| ASTM B88 | C11000 | O200 | O0.025 | – | O50 |
| O200 | O0.040 | – | O60 | ||
| C12200 | O250 | – | – | H58 | |
| ASTM B75 | C11000 | O205 | O0.040 | – | O50 |
| O205 | O0.040 | – | O60 | ||
| C12200 | O310 | – | – | H80 | |
| O250 | – | – | H58 | ||
Application of Copper Tube For Heating Application Solar Panels
Oil & Gas Industries
Petrochemical Industries
Medical & HealthCare Industries
Construction & Plumbing Industries
(EV) Automobiles Industries
Copper Tube for Heating Application & Solar Panels Stock Available
- Copper Brazed Plate Heat Exchanger
- Copper Tube For Heat Exchangers and Locomotives
- Copper Tube Coil Immersion Heat Exchanger
- Copper Tube Heat Exchanger
- Copper Coil Heat Exchanger
- Finned Copper Tube Heat Exchanger
- Spiral Copper Tube Heat Exchanger
- Copper Shell and Tube Heat Exchanger
- Copper Welded Heating Tube
Packaging of Copper Tube for Heating Application & Solar Panels
Types of Packaging Available
Copper tubes for heating applications and solar panels are packed using durable, industry-standard methods to ensure safe handling, easy transportation, and complete protection from physical or environmental damage. These packaging options maintain tube quality and prevent contamination during storage or shipment.
- Wooden Box Packaging
- Steel Bundle Packaging
- Coil & Reel Packaging
Copper Tube for Heating Application & Solar Panels Manufacturer, Supplier and Exporter - United copper Industries
Cities We Supply Copper Tube for Heating Application & Solar Panels in India
| Cities We Supply Copper Tube for Heating Application & Solar Panels in India | |||
| Gujarat | Delhi | Mumbai | Ahmedabad |
| Surat | Gandhinagar | Visakhapatnam | Pune |
| Patna | Indore | Faridabad | Ghaziabad |
| Goa | Guwahati | Bhosari | Hubli |
| Jabalpur | Jamshedpur | Kanpur | Kochi |
| Prayagraj | Vijayawada | Rajkot | Meerut |
| Noida | Kolkata | Lucknow | Raipur |
| Ranchi | Rajasthan | Hyderabad | Bhubaneswar |
| Thane | Varanasi | Vadodara | Coimbatore |
Copper Tube for Heating Application & Solar Panels Exporter
Germany
Brazil
Malaysia
Qatar
Kuwait
Saudi
Oman
USA
UAE
